Teaching in a program
17.4 Teach-in via Windows
Turning
744 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
8. Press the "Accept" softkey.
A new program block will be inserted at the cursor position.
- OR -
Press the "Cancel" softkey to cancel your input.
17.4.2 Teach in rapid traverse G0
You traverse the axes and teach-in a rapid traverse block with the approached positions.
Note
Selection of axes and parameters for teach-in
You can select the axes to be included in the teach-in block in the "Settings" window.
You also specify here whether motion and transition parameters are offered for teach-in.
17.4.3 Teach in straight G1
You traverse the axes and teach-in a machining block (G1) with the approached positions.
Note
Selection of axes and parameters for teach-in
You can select the axes to be included in the teach-in block in the "Settings" window.
You also specify here whether motion and transition parameters are offered for teach-in.
