Programming technology functions (cycles)
8.1 Drilling
Turning
Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
309
Parameter Description Unit
X0
C0
Y0
Z0
α0
(only for
ShopTurn)
Peripheral surface Y:
X coordinate of the reference point (abs)
Positioning angle for machining surface
Y coordinate of the reference point – first position (abs)
Z coordinate of the reference point – first position (abs)
Angle of rotation of line with reference to Y axis
Positive angle: Line is rotated counterclockwise.
Negative angle: Line is rotated clockwise.
mm
Degrees
mm
mm
Degrees
L0
L
N
Line
Distance of the 1st position to reference point
Distance between the positions
Number of positions - (for line position pattern only)
mm
mm
αX
αY
L1
L2
N1
N2
Grid or frame
Shear angle X
Shear angle Y
Distance between columns
Distance between rows
Number of columns
Number of rows
Degrees
Degrees
mm
mm
8.1.12 Circle position pattern (HOLES2)
Function
You can program holes on a full circle or pitch circle with defined radius with the "Circle
position pattern" cycle. The basic angle of rotation (α0) for the 1st position is relative to the X
axis. The control calculates the angle of the next hole position as a function of the total
number of holes. The angle it calculates is identical for all positions.
The tool can approach the next position along a linear or circular path.
Procedure
1. The part program or ShopTurn program to be processed has been
created and you are in the editor.
2. Press the "Drilling" softkey.
3.
Press the "Positions" and "Full circle" softkeys.
The "Position circle" input window opens.
In the "Full/pitch circle" field, use the cursor to select "Full circle".
