Creating a ShopTurn program
7.12 Changing program blocks
Turning
244 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
Procedure
1. Open the "Program end" program block, if you want to machine more
than one workpiece.
2. In the "Repeat" field, enter "Yes".
3. Press the "Accept" softkey.
If you start the program later, program execution is repeated.
Depending on the settings in the "Times, counters" window, the
program is repeated until the set number of workpieces has been
machined.
See also
Displaying the program runtime and counting workpieces (Page 171)
7.12 Changing program blocks
You can subsequently optimize the parameters in the programmed blocks or adapt them to
new situations, e.g. if you want to increase the feedrate or shift a position. In this case, you
can directly change all the parameters in every program block in the associated parameter
screen form.
Procedure
1. Select the program that you wish to change in the "Program Manager"
operating area.
2. Press the <Cursor right> or <INPUT> key.
The work plan of the program is displayed.
3. Position the cursor in the work plan at the desired program block and
press the <Cursor right> key.
The parameter screen for the selected program block is displayed.
4. Make the desired changes.
5. Press the "Accept" softkey.
- OR -
