Setting up the machine
2.7 Zero offsets
Turning
Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
83
You can save the workpiece zero, for example, in the coarse offset, and then store the offset
that occurs when a new workpiece is clamped between the old and the new workpiece zero
in the fine offset.
Note
Deselect fine offset (only 840D sl)
You have the option of deselecting the fine offset using machine data MD18600
$MN_MM_FRAME_FINE_TRANS
See also
Actual value window (Page 42)
2.7.1 Display active zero offset
The following zero offsets are displayed in the "Zero Offset - Active" window:
● Zero offsets, for which active offsets are included, or for which values are entered.
● Settable zero offsets
● Total zero offset
This window is generally used only for monitoring.
The availability of the offsets depends on the setting.
Machine manufacturer
Please refer to the machine manufacturer's specifications.
