Simulating machining
5.8 Program control during the simulation
Turning
Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
191
5.8.2 Simulating the program block by block
You can control the program execution during simulation, i.e. execute a program block by
block, as when executing a program.
Procedure
1. Simulation is started.
2. Press the "Program control" and "Single block" softkeys.
3. Press the "Back" and "Start SBL" softkeys.
The pending block of the program is simulated and then stops.
4. Press "Start SBL" as many times as you want to simulate a single
program block.
5. Press the "Program control" and the "Single block" softkeys to exist the
single block mode.
Note
Enabling/disabling single block
+
6
Press the <CTRL> and <S> keys simultaneously to enable and disable
the single block mode.
