Programming technology functions (cycles)
8.3 Contour turning
Turning
370 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
parameters Description Unit
XDB 2. Grooving limit tool (abs) – (only for face machining direction) mm
UX or U Finishing allowance in X or finishing allowance in X and Z – (only for ∇) mm
UZ Finishing allowance in Z – (only for UX) mm
DI For zero: Continuous cut - (only for ∇) mm
Allowance Allowance for pre-finishing - (only for ∇∇∇)
• Yes
U1 contour allowance
• No
mm
U1 Compensation allowance in X and Z direction (inc) – (only for allowance)
• Positive value: Compensation allowance is kept
• Negative value: Compensation allowance is removed in addition to finishing
allowance
mm
Set machining area
limits
Set machining area limits
• Yes
• No
XA
XB
ZA
ZB
with limited machining area only, yes:
1. Limit XA ∅
2. Limit XB ∅ (abs) or 2nd limit referred to XA (inc)
1. Limit ZA
2. Limit ZB (abs) or 2nd limit referred to ZA (inc)
mm
N Number of grooves
DP Distance between grooves (inc) mm
* Unit of feedrate as programmed before the cycle call
8.3.12 Plunge-turning (CYCLE952)
Function
Using the "Plunge turning" function, you can machine any shape of groove.
Contrary to grooving, the plunge turning function removes material on the sides after the
groove has been machined in order to reduce machining time. Contrary to stock removal, the
plunge turning function allows you to machine contours that the tool must enter vertically.
You will need a special tool for plunge turning. Before you program the "Plunge turning"
cycle, you must define the contour.
Blank
For plunge turning, the cycle takes into account a blank that can consist of a cylinder, an
allowance on the finished-part contour or any other blank contour.
