Programming technology functions (cycles)
8.7 Additional cycles and functions in ShopTurn
Turning
502 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
8.7.8 Rotation C
You can rotate the C axis through a specific angle to enable subsequent machining
operations to be performed at a particular position on the face or peripheral surface.
The direction of rotation is set in a machine data element.
Machine manufacturer
Please refer to the machine manufacturer's specifications.
New C axis rotation
Additive C axis rotation
Parameters Description Unit
Rotation
• New
New rotation
• Additive
Additive rotation
C Rotation C Degrees
