Ladder Viewer and Ladder add-on (828D only)
23.11 Editing block properties subsequently
Turning
796 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
4. Enter author, number of the INT block and, if required, a comment.
The data class of the block is specified.
5. Press the "OK" softkey to transfer the block to the list.
23.11 Editing block properties subsequently
You can edit the title, author and comments of an INT block.
Note
You cannot edit the block name, subprogram number and data class assignment.
Procedure
1. The ladder diagram display is opened.
2. Select the relevant block and press the "Program block" softkey.
3. Press the "Properties" softkey.
The "Properties" window appears.
