Working with a B axis (only 840D sl)
15.2 Tool alignment for turning
Turning
728 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
15.2 Tool alignment for turning
The input fields for the β and γ angles for aligning the tool are available in the tool screen
and in all turning screens.
β angle
In the entry field "β" you have the possibility of selecting the main alignment of the tool:
•
: β = 0°
•
: β = 90°
•
Empty : The required angle can be freely entered
Programming when machining with a counterspindle
When machining on the counterspindle, it is programmed in exactly the same way as the
main spindle.
The direction display of the arrows depends on the settings.
Machine manufacturer
Please refer to the machine manufacturer's specifications.
γ angle
In the entry field "γ" you have the possibility of selecting the main alignment of the tool:
● 0°
● 180°
- or -
● Free entry field to enter the required angle
Machine manufacturer
Please refer to the machine manufacturer's specifications.
