Multi-channel machining (only 840D sl)
9.2 Multi-channel support (only 840D sl)
Turning
562 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
6. In the associated selection field of a channel, select "Yes" if the WAIT
mark for this channel is to be valid.
7. Press the "Accept" softkey.
The WAIT mark is displayed in the program as machining step.
Using "Cursor right", as usual, open the machining step in the editor.
Editing a WAIT mark
+
Press the keys <SHIFT> and <INSERT > to open the WAIT mark and
edit it
9.2.9 Optimizing the machining time
After simulating a program, the machining time is displayed for the blocks.
For a multi-channel display, the wait times that occur are displayed at the wait points (wait
marks). This provides you with an overview of the time sequence of the program and you
can perform the first optimization runs.
Shifting blocks
For instance, you have the option of shifting program blocks to longer wait points - assuming
that the machining technology permits this - therefore reducing the machining time.
1. Select the block that you wish to shift.
2. Press the "Mark" softkey.
3. Press the "Copy" softkey if you wish to repeat the machining step at
another position.
- OR -
Press the "Cut-out" softkey if you wish to execute the machining step at
another position.
4. Position the cursor at the required program position and press the
"Paste" softkey.
Insert the program block at the required position.
