Managing programs
12.4 Creating a directory / program / job list / program list
Turning
Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
649
Enter a name and file format for the file to be created (e.g. My_Text.txt).
The name can be a maximum of 24 characters long.
You can use any letters (except accented), digits or the underscore
symbol (_).
5. Press the "OK" softkey.
12.4.6 Creating a job list
For every workpiece, you can create a job list for extended workpiece selection.
In the job list, you specify instructions for program selection in different channels.
Syntax
The job list contains the SELECT instructions.
SELECT <program> CH=<channel number> [DISK]
The SELECT instruction selects a program for execution in a specific NC channel. The
selected program must be loaded into the working memory of the NC. The DISK parameter
enables the selection of external execution (CF card, USB data carrier, network drive).
● <Program>
Absolute or relative path specification of the program to be selected.
Examples:
– //NC/WCS.DIR/SHAFT.WPD/SHAFT1.MPF
– SHAFT2.MPF
● <Channel number>
Number of the NC channel in which the program is to be selected.
Example:
CH=2
● [DISK]
Optional parameter for programs that are not in the NC memory and are to be executed
"externally".
Example:
SELECT //remote/myshare/shaft3.mpf CH=1 DISK
Comment
Comments are identified in the job list by ";" at the start of the line or by round brackets.
