Setting up the machine
2.7 Zero offsets
Turning
Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
89
- OR -
Press the "Clear offset" softkey to reset all entered values.
...
Press the "ZO +" or "ZO -" softkey to select the next or previous offset,
respectively, within the selected area ("Active", "Base", "G54 to G599")
without first having to switch to the overview window.
If you have reached the end of the range (e.g. G599), you will switch
automatically to the beginning of the range (e.g. G54).
These value changes are available in the part program immediately or after "Reset".
Machine manufacturer
Please refer to the machine manufacturer's specifications.
Press the "Back" softkey to close the window.
2.7.6 Deleting a zero offset
You have the option of deleting zero offsets. This resets the entered values.
Procedure
1. Select the "Parameter" operating area.
2. Press the "Zero offset" softkey.
3. Press the "Active", "Base" or "G54…G599" softkey.
