Simulating machining
5.3 Simultaneous recording before machining of the workpiece
Turning
182 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
Press the "Reset" softkey to cancel the simulation.
6. Press the "Start" softkey to restart or continue the simulation.
Note
Operating area switchover
The simulation is exited if you switch into another operating area. If you restart the
simulation, then this starts again at the beginning of the program.
Software option
You require the option "3D simulation of the finished part" for the 3D
view.
5.3 Simultaneous recording before machining of the workpiece
Before machining the workpiece on the machine, you can graphically display the execution
of the program on the screen to monitor the result of the programming.
You can replace the programmed feedrate with a dry run feedrate to influence the speed of
execution and select the program test to disable axis motion.
If you would like to view the current program blocks again instead of the graphical display,
you can switch to the program view.
Software option
You require the option "Simultaneous recording (real-time simulation)" for the
simultaneous recording.
Procedure
1. Load a program in the "AUTO" mode.
2. Press the "Prog. ctrl." softkey and activate the checkboxes "PRT no axis
movement" and "DRY run feedrate".
The program is executed without axis movement. The programmed
feedrate is replaced by a dry run feedrate.
3. Press the "Sim. rec." softkey.
