Setting up the machine
2.9 Displaying setting data lists
Turning
Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
95
Parameter Description Unit
ZC1 Main spindle chuck dimensions (inc) mm
Jaw type Dimensions of the forward edge or stop edge
• Jaw type 1
• Jaw type 2
ZC3 Chuck dimension, counter-spindle (inc) - only for a counter-spindle that has been
set-up
mm
ZS3 Stop dimension, counter-spindle (inc) - only for a counter-spindle that has been
set-up
mm
ZE3 Jaw dimension, counter-spindle (inc) - only for a counter-spindle that has been
set-up and "Jaw type 2"
mm
XR Tailstock diameter - only for tailstock that has been set-up mm
ZR Tailstock length - only for tailstock that has been set-up mm
2.9 Displaying setting data lists
You can display lists with configured setting data.
Machine manufacturer
Please refer to the machine manufacturer's specifications.
Procedure
1. Select the "Parameter" operating area.
2. Press the "Setting data" and "Data lists" softkeys.
The "Setting Data Lists" window opens.
3. Press the "Select data list" softkey and in the "View" list, select the
required list with setting data.
