Setting up the machine
2.8 Monitoring axis and spindle data
Turning
94 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
Tailstock
;5
=5
Dimensioning the tailstock
The length of the tailstock (ZR) and the diameter of the tailstock (XR) of the spindle screen
are needed for the display of the tailstock in the simulation.
Procedure
1. Select the "Parameter" operating area.
2. Press softkeys "Setting data" and "Spindle chuck data".
The "Spindle chuck data" window opens.
3. Enter the desired parameter.
The settings become active immediately.
See also
Machining with movable counterspindle (Page 517)
