Page #184 background image
Simulating machining
5.5 Different views of the workpiece
Turning
184 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
5.5 Different views of the workpiece
In the graphical display, you can choose between different views so that you constantly have
the best view of the current workpiece machining, or in order to display details or the overall
view of the finished workpiece.
The following views are available:
Side view
Half section
Front view
3D view
2-window
5.5.1 Side view
1. Start the simulation.
2. Press the "Side view" softkey.
The side view shows the workpiece in the Z-X plane.
Changing the display
You can increase or decrease the size of the simulation graphic and move it, as well as
change the segment.
5.5.2 Half section
1. Start the simulation.
2. Press the "Other views" and "Half section" softkeys.
The half view shows the workpiece cut in the Z-X plane.
Changing the display
You can increase or decrease the size of the simulation graphic and move it, as well as
change the segment.
