Multi-channel machining (only 840D sl)
9.2 Multi-channel support (only 840D sl)
Turning
534 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
In the multi-channel editor, you have the option of simultaneously opening several programs
and editing them. In this case, the multi-channel editor supports you regarding program
synchronization from a time perspective.
Software options
You require the "programSYNC" option to generate and edit synchronized
programs in the multi-channel editor.
9.2.2 Creating a multi-channel program
All of the programs involved in a multi-channel machining operation are combined in one
workpiece.
In a job list, enter the program names, define the program type - G code or ShopTurn
program - and assign these to a channel.
Software options
You require the "ShopMill/ShopTurn" option to generate and edit ShopTurn
programs.
Machine manufacturer
If you only program G code programs, then you can switch-out the multi-channel
view.
Please refer to the machine manufacturer's specifications.
Requirement
● "programSYNC" option
Procedure
1. Select the "Program Manager" operating area.
2. Press the "NC" softkey and select the "Workpieces" folder.
3. Press the "New" and "programSYNC multi-channel" softkeys.
The "New job list" window opens.
