Programming technology functions (cycles)
8.3 Contour turning
Turning
374 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
Parameter Description Unit
N Number of grooves
DP Distance between grooves mm
* Unit of feedrate as programmed before the cycle call
8.3.13 Plunge-turning rest (CYCLE952)
Function
The "Plunge turning residual material" function is used when you want to machine the
material that remained after plunge turning.
For plunge turning ShopTurn, the cycle automatically detects any residual material and
generates an updated blank contour. For a G code program, the function must have been
previously selected in the screen. Material that remains as part of the finishing allowance is
not residual material. The "Plunge turning residual material" function allows you to remove
unwanted material with a suitable tool.
Software option
To machine residual material, you require the "Residual material detection
and machining" option.
Procedure
1. The part program or ShopTurn program to be processed has been
created and you are in the editor.
2. Press the "Contour turning" softkey.
3. Press the "Plunge turning residual material" softkey.
The "Plunge turning residual material" input window opens.
