Programming technology functions (cycles)
8.1 Drilling
Turning
Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
283
Parameter Description Unit
Z1
Drilling depth (abs) or drilling depth in relation to Z0 (inc)
It is inserted into the workpiece until it reaches Z1.
mm
DT
• Dwell time (at final drilling depth) in seconds
• Dwell time (at final drilling depth) in revolutions
s
rev
8.1.4 Reaming (CYCLE85)
Function
With the "Reaming" cycle, the tool is inserted in the workpiece with the programmed spindle
speed and the feedrate programmed at F.
If Z1 has been reached and the dwell time expired, the reamer is retracted at the
programmed retraction feedrate to the retraction plane.
Clamping the spindle
For ShopTurn, the "Clamp spindle" function can be set up by the machine manufacturer.
Machine manufacturer
Please refer to the machine manufacturer's specifications.
See also
Clamping the spindle (Page 231)
Approach/retraction
1. The tool moves with G0 to safety clearance of the reference point.
2. The tool is inserted into the workpiece with the programmed feedrate F until it reaches
the final depth Z1.
3. Dwell time DT at final drilling depth.
4. Retraction to retraction plane with programmed retraction feedrate FR.
