Programming technology functions (cycles)
8.1 Drilling
Turning
282 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
Parameters, G code program Parameters, ShopTurn program
PL Machining plane T Tool name
RP Retraction plane mm D Cutting edge number
SC Safety clearance mm F
Feedrate mm/min
mm/rev
S / V
Spindle speed or constant
cutting rate
rpm
m/min
Parameter Description Unit
Machining
position (only
for G code)
• Single position
Drill hole at programmed position
• Position pattern
Position with MCALL
Z0 (only for G
code)
Reference point Z mm
Machining
surface
(only for
ShopTurn)
• Face C
• Face Y
• Peripheral surface C
• Peripheral surface Y
Position
(only for
ShopTurn)
• At the front (face)
• At the rear (face)
• Outside (peripheral surface)
• Inside (peripheral surface)
(only for
ShopTurn)
Clamp/release spindle
The function must be set up by the machine manufacturer.
Drilling depth
• Shank (drilling depth in relation to the shank)
The drill is inserted into the workpiece until the drill shank reaches the value
programmed for Z1. The angle entered in the tool list is taken into account.
• Tip (drilling depth in relation to the tip)
The drill is inserted into the workpiece until the drill tip reaches the value
programmed for Z1.
Note: If it is not possible to define an angle for the drill in the tool management, it will
not be possible to select tip or shank (always tip, 0 field)
