Managing programs
12.17 RS-232-C
Turning
680 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
12.17 RS-232-C
12.17.1 Reading-in and reading-out archives
Availability of the RS-232-C serial interface
You have the option of reading-out and reading-in archives in the "Program manager"
operating area as well as in the "Start-up" operating area via the RS-232-C serial interface.
● SINUMERIK Operate on the NCU:
The softkeys for the RS-232-C are available as soon as an option module is connected
and the slot is occupied.
● SINUMERIK Operate on the PCU:
The softkeys for the RS-232-C are always available.
Reading-out archives
The files to be sent (directories or individual files) are zipped in an archive (*.ARC). If you
send an archive (*.arc), this is sent directly without being additionally zipped. If you have
selected an archive (*.arc) together with an additional file (e.g. directory), then these are
zipped into a new archive and are then sent.
Reading-in archives
Only archives can be read-in via the RS-232-C. These are transferred and then
subsequently unzipped.
Note
Start-up archive
If you read in a start-up archive via the RS-232-C, then this is immediately activated.
Externally processing the punched tape format
If you wish to externally process an archive, then generate this in the punched tape format.
Using the SinuCom commissioning and service tool SinuCom ARC, you can process the
archive in the binary format and in the commissioning archive.
