Machining the workpiece
4.12 Displaying G functions and auxiliary functions
Turning
160 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
Procedure
1. Select the "Machine" operating area.
...
2.
Press the <JOG>, <MDA> or <AUTO> key.
3. Press the ">>" and "All G functions" softkeys.
The "G Functions" window is opened.
4.12.3 G functions for mold making
In the window "G functions", important information for machining free-form surfaces can be
displayed using the "High Speed Settings" function (CYCLE832).
Software option
You require the "Advanced Surface" software option in order to use this function.
High-speed cutting information
In addition to the information that is provided in the "All G functions" window, the following
programmed values of the following specific information is also displayed:
● CTOL
● OTOL
● STOLF
The tolerances for G0 are only displayed if they are active.
Particularly important G groups are highlighted.
You have the option to configure which G functions are highlighted.
