Ladder Viewer and Ladder add-on (828D only)
23.10 Creating a new block
Turning
Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
795
6. Press the "Attach line" softkey if you want to add a further variable and
enter the data.
- OR -
Select the relevant variable and press the "Delete line" softkey to
remove the variable from the list.
23.10 Creating a new block
Create INT blocks to make changes in the PLC user program.
Name INT _100, INT_101
The number from the selection field "Number of subprogram" is taken
for the name of the INT block.
Author A maximum of 48 characters is permitted.
Number of
subprogram
100, 101
Data class Individual
Comment A maximum of 100 lines and 4096 characters are permitted.
Note
Access protection
You have the option of protecting blocks that have been newly created against being
accessed.
Procedure
...
1. The ladder diagram display (LAD) is opened.
2. Press the "Program block" softkey to open the list of program blocks.
3. Press the "Add" softkey.
The "Properties" window appears.
