Multi-channel machining (only 840D sl)
9.2 Multi-channel support (only 840D sl)
Turning
Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
535
4. Enter the required name and press the "OK" softkey.
The "Job list *.JOB" window opens.
For each channel that has been set-up, the window has one line to
input or select the assigned program.
5. Position the cursor on the required channel line, enter the required
program name and select the program type (G code or ShopTurn).
6. Press the "OK" softkey.
The "Multi-channel data" parameter screen opens in the editor.
9.2.3 Entering multi-channel data
In the parameter screen "multi-channel data", enter the following data, which apply for all
channels for G code and ShopTurn programs:
● Measurement unit
● Work offset (e.g. G54)
● Z value of the work offset (optional)
● Blank
● Spindle chuck data (optional)
● Speed limitation
● if required, data for the counter spindle
● Counterspindle with/without mirroring (for G code)
The data defined here are saved as cycle call in the job list.
Machine manufacturer
If you are working with pure G code programming, it is possible that the parameter
screen "multi-channel data" does not open.
Please refer to the machine manufacturer's instructions.
