Machining the workpiece
4.7 Starting machining at a specific point
Turning
128 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
4.7.3 Simple search target definition
Requirement
The program is selected and the controller is in Reset mode.
Procedure
1. Press the "Block search" softkey.
2. Place the cursor on a particular program block.
- OR -
Press the "Find text" softkey, select the search direction, enter the
search text and confirm with "OK".
3. Press the "Start search" softkey.
The search starts. Your specified search mode will be taken into
account.
The current block will be displayed in the "Program" window as soon
as the target is found.
4. If the located target (for example, when searching via text) does not
correspond to the program block, press the "Start search" softkey
again until you find your target.
Press the <CYCLE START> key twice.
Processing is continued from the defined position.
