8.1.9 Positions and position patterns
Function
After you have programmed the technology (cycle call), you must program the positions.
Several position patterns are available:
● Arbitrary positions
● Position on a line, on a grid or frame
● Position on a full or pitch circle
Programming a position pattern in ShopTurn
Several position patterns can be programmed in succession (up to 20 technologies and
position patterns in total). They are executed in the order in which you program them.
Note
The number of positions that can be programmed in the one "Positions" step is limited to a
maximum of 400!
The programmed technologies and subsequently programmed positions are automatically
linked by the control.
Displaying and hiding positions
You can display or hide any positions (Section "Displaying and hiding positions (Page 313)").
8.1.9.1 Approach/retraction
Approach/retraction
1. Within a position pattern, or while approaching the next position pattern, the tool is
retracted to the retraction plane and the new position or position pattern is then
approached at rapid traverse.
2. With technological follow-up operations (e.g. centering - drilling - tapping), the respective
drilling cycle must programmed after calling the next tool (e.g. drill) and immediately
afterwards the call of the position pattern to be machined.
