Managing programs
12.3 Executing a program
Turning
Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
643
12.3 Executing a program
When you select a program for execution, the controller automatically switches to the
"Machine" operating area.
Program selection
Select the workpieces (WPD), main programs (MPF) or subprograms (SPF) by placing the
cursor on the desired program or workpiece.
For workpieces, the workpiece directory must contain a program with the same name. This
program is automatically selected for execution (e.g. when you select the workpiece
SHAFT.WPD, the main program SHAFT.MPF is automatically selected).
If an INI file of the same name exists (e.g. SHAFT.INI), it will be executed once at the first
part program start after selection of the part program. Any additional INI files are executed in
accordance with machine data MD11280 $MN_WPD_INI_MODE.
MD11280 $MN_WPD_INI_MODE=0:
The INI file with the same name as the selected workpiece is executed. For example, when
you select SHAFT1.MPF, the SHAFT1.INI file is executed upon <CYCLE START>.
MD11280 $MN_WPD_INI_MODE=1:
All files of type SEA, GUD, RPA, UFR, PRO, TOA, TMA and CEC which have the same
name as the selected main program are executed in the specified sequence. The main
programs stored in a workpiece directory can be selected and processed by several
channels.
Machine manufacturer
Please refer to the machine manufacturer's specifications.
Procedure
1. Select the "Program Manager" operating area.
2. Select the desired storage location and position the cursor on the
workpiece/program that you would like to execute.
3. Press the "Select" softkey.
The controller switches automatically into the "Machine" operating area.
- OR -
