Programming technology functions (cycles)
8.7 Additional cycles and functions in ShopTurn
Turning
Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
511
Parameters Description Unit
X
Z
Machining plane rotation
Target position X ∅ (abs) or target position Y referred to the last programmed
position (inc)
Target position Z (abs) or target position X referred to the last programmed
position (inc)
Note:
Incremental dimension: The sign is also evaluated.
mm
mm
R
Radius of circular arc
The sign determines the type of arc traversed.
mm
mm
F Machining feedrate. mm/rev
mm/min
mm/tooth
8.7.14 Polar coordinates
If a workpiece has been dimensioned from a central point (pole) with radius and angles, you
will find it helpful to program these dimensions as polar coordinates.
Before you program a straight line or circle in polar coordinates, you must define the pole,
i.e. the reference point, of the polar coordinate system.
Procedure
1. The ShopTurn program to be processed has been created and you are
in the editor.
2. Press the menu forward key and the "Straight Circle" softkey.
3. Press the "Polar" and "Pole" softkeys.
