Programming technology functions (cycles)
8.7 Additional cycles and functions in ShopTurn
Turning
510 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
Procedure
1. The ShopTurn program to be processed has been created and you are
in the editor.
2. Press the menu forward key and the "Straight Circle" softkey.
3. Press the "Circle radius" softkey.
Parameters Description Unit
Direction of rotation Direction of rotation in which the tool travels from the circle starting point to the
circle end point
Direction of rotation clockwise (right)
Direction of rotation counterclockwise (left)
Y
Z
Machining plane peripheral surface/peripheral surface C
Target position Y (abs) or target position X referred to the last programmed
position (inc)
Target position Z (abs) or target position Y referred to the last programmed
position (inc)
Note:
Incremental dimension: The sign is also evaluated
mm
mm
Y
Z
Machining plane, peripheral surface Y
Target position Y (abs) or target position X referred to the last programmed
position (inc)
Target position Z (abs) or target position Y referred to the last programmed
position (inc)
Note:
Incremental dimension: The sign is also evaluated.
mm
mm
X
Y
Machining plane face/face C
Target position X (abs) or target position X referred to the last programmed
position (inc)
Target position Y (abs) or target position Y referred to the last programmed
position (inc)
Note:
Incremental dimension: The sign is also evaluated
mm
mm
X
Y
Machining plane face Y
Target position X (abs) or target position X referred to the last programmed
position (inc)
Target position Y (abs) or target position Y referred to the last programmed
position (inc)
Note:
Incremental dimension: The sign is also evaluated.
mm
mm
