14.5 Simple workpiece machining
Turning
714 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
Using the "Graphic view" softkey, you can toggle between the help
screen and the graphic view in the screen.
Parameter Description Unit
F
Feedrate mm/min
mm/rev
All axes
X
Z
Y
C
Z2
Target position in the X direction (abs or inc)
Target position in the Z direction (abs or inc)
Target position in the Y direction (abs or inc)
Target position of C axis of main spindle (abs or inc)
Target position of an added axis, if it exists (abs or inc)
mm
mm
mm
mm
mm
Straight X α
X
α
Target position in the X direction (abs or inc)
Angle of the straight line to the X axis
mm
Degrees
Straight Z α
Z
α
Target position in the Z direction (abs or inc)
Angle of the straight line to the Z axis
mm
Degrees
14.5.3.2 Circular turning
You can use this function for a simple circular machining.
Procedure
1. "Manual Machine" is active.
2. Press the "Straight circle" softkey.
3. Press the "Circle" softkey.
4. Specify the desired value for the feedrate F.
5. Select the desired circle input (e.g. "End point + radius") and the
direction of rotation.
6. Enter the target position as well as the circle center point or radius.
Using the "Graphic view" softkey, you can toggle between the help
screen and the graphic view in the screen.
