13.8 Creating screenshots
Turning
702 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
13.8 Creating screenshots
You can create screenshots of the current user interface.
Each screenshot is saved as a file and stored in the following folder:
/user/sinumerik/hmi/log/screenshot
Procedure
Ctrl + P Press the <Ctrl+P> key combination.
A screenshot of the current user interface is created in .png format.
The file names assigned by the system run in ascending order from
"SCR_SAVE_0001.png" to "SCR_SAVE_9999". You can create up to 9,999
screenshots.
Copy file
1. Select the "Start-up" operating area.
2. Press the "System data" softkey and open the specified folder.
As you cannot open screenshots in SINUMERIK Operate, you must
copy the files to a Windows PC either via "WinSCP" or via a USB-
FlashDrive.
You can open the files using a graphics program, e.g. "Office Picture
Manager".
