Machining the workpiece
4.7 Starting machining at a specific point
Turning
Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
127
Preconditions
1. You have selected the desired program.
2. The controller is in the reset state.
3. The desired search mode is selected.
NOTICE
Risk of collision
Pay attention to a collision-free start position and appropriate active tools and other
technological values.
If necessary, manually approach a collision-free start position. Select the target block
considering the selected block search type.
Toggling between search pointer and search positions
Press the "Search pointer" softkey again to exit the "Search Pointer"
window and return to the "Program" window to define search positions.
- OR -
Press the "Back" softkey.
You have now exited the block search function.
See also
Selecting a program (Page 118)
4.7.2 Continuing program from search target
To continue the program at the desired position, press the <CYCLE START> key twice.
● The first CYCLE START outputs the auxiliary functions collected during the search. The
program is then in the Stop state.
● Before the second CYCLE START, you can use the "Overstore" function to create states
that are required, but not yet available, for the further program execution.
By changing to the JOG REPOS mode, you can also manually traverse the tool from the
current position to the setpoint position, if the setpoint position is not to be automatically
approached after the program start
