Turning
Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
767
Easy Message (828D only)
20
20.1 Overview
Easy Message enables you to be informed about certain machine states by means of SMS
messages via a connected modem:
● For example, you would like to be informed about emergency stop states
● You would like to know when a batch has been completed
Control commands
● HMI commands are used to activate or deactivate a user.
Syntax: [User ID] deactivate¸ [User ID] activate
● A special area is reserved in the PLC to which you can send commands in the form of
PLC bytes using SMS commands.
Syntax: [User ID] PLC DataByte
The user ID is optional and required only if a corresponding ID has been specified in the
user profile. The string PLC indicates that a PLC byte is to be written. It is followed by the
data byte to be written in the following format: Base#Value. Base can take the values 2,
10 and 16 and defines the number base. Then follows the separator # and the value of
the byte. Only positive values are allowed to be sent.
Examples:
2#11101101
10#34
16#AF
Machine manufacturer
Please refer to the machine manufacturer's specifications.
Active users
In order to receive an SMS message for certain events, you must be activated as user.
User logon
As registered user, you can log on via SMS to inquire about messages.
