Introduction
1.4 User interface
Turning
38 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
1.4 User interface
1.4.1 Screen layout
Overview
 

 
 





1 Active operating area and mode
2 Alarm/message line
3 Program name
4 Channel state and program control
5 Channel operational messages
6 Axis position display in actual value window
