Alarm, error and system messages
13.6 Version
Turning
Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
697
4. Press the "Details" softkey, in order to receive more exact information
on the components displayed.
13.6.2 Save information
All the machine-specific information of the control is combined in a configuration via the user
interface. You can save machine-specific information on the drives that have been set-up.
Procedure
1. Select the "Diagnostics" operating area.
2. Press the "Version" softkey.
It takes some time to call the version display. While the version data is
being determined a progress message box and the appropriate text are
displayed in the dialog line.
3. Press the "Save" softkey.
The "Save Version Information: Select Archive" window opens. The
following storage locations are offered depending on the configuration:
• Local drive
• Network drives
• USB
• Version data (archive: Data tree in the "HMI data" directory)
4. Then press the "New directory" softkey if you wish to create your own
directory.
5. Press the "OK" softkey. The directory is created.
6. Press the "OK" softkey again to confirm the storage location.
