Ladder Viewer and Ladder add-on (828D only)
23.16 Searching for operands
Turning
802 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
23.16 Searching for operands
You can use the search function to quickly reach points in very large programs where you
would like, for example, to make changes.
Restricting the search
● "Window 1" / "Window 2","Symbol table"
With "Go to", you can jump directly to the desired network.
● "Cross references"
With "Go to", you can jump directly to the desired line.
Requirement
Window 1 / window 2, the symbol tables or the list of cross references is opened.
Procedure
1. Press the "Find" softkey.
new vertical softkey bar appears. The "Find / Go To" window opens at
the same time.
2. Select the "Find operand" entry in the first input field if you are
searching for a specific operand and enter the search term in the "Find"
input field.
3. Select the search range (e.g. Find all).
4. Select the "In this program unit" or "In all program units" entry if you are
in "Window 1" or "Window 2" or in the symbol table in order to restrict
the search.
5. Press the "OK" softkey to start the search.
If the operand you are searching for is found, the corresponding line is
highlighted.
Press the "Continue search" softkey if the operand found during the
search does not correspond to the element you are looking for.
- OR -
Press the "Cancel" softkey if you want to cancel the search.
