Ladder Viewer and Ladder add-on (828D only)
23.15 Displaying and editing symbol tables
Turning
Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
801
3. Select the desired table and press the "Open" softkey.
The display fields can be edited.
4. Use the cursor keys to select the desired entry and the field to be
changed.
5. Enter the value to be changed.
- OR -
Press the "Attach line" softkey to insert an empty line after the selected
entry.
- OR -
Press the "Delete line" softkey to remove the selected entry from the
list.
- OR -
Enter a new value in the selected field.
6. Press the "OK" softkey to confirm your action.
