Managing programs
12.1 Overview
Turning
640 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
Procedure
1. Select the "Program manager" operating area.
2. Press the "USB" softkey.
Note
The "USB" softkey can only be operated when a USB-FlashDrive is inserted in the front
interface of the operator panel.
12.1.5 FTP drive
The FTP drive offers you the following options - to transfer data, e.g. part programs, between
your control system and an external FTP server.
You have the option of archiving any files in the FTP server by creating new directories and
subdirectories.
Note
Selecting a program / execution
It is not possible to select a program directly on the FTP drive, and change to execution in
the "Machine" operating area.
Precondition
User name and password have been set up in the FTP server.
Procedure
1. Select the "Program manager" operating area.
2. Press the "FTP" softkey.
When selecting the FTP drive for the first time, a login window is
displayed.
