Managing programs
12.12 Set up drives
Turning
662 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
12.12.2 Setting up drives
The "Set Up Drives" window is available in the "Start-up" operating area for configuration.
File
The created configuration data is stored in the "logdrive.ini" file. This file is located in the
/user/sinumerik/hmi/cfg directory.
General information
Entry Meaning
No drive No drive defined.
USB local Access to the USB memory medium is only realized via
the TCU to which it is connected.
USB drives are automatically identified if the memory
medium is inserted when SINUMERIK Operate powers-
up.
USB global All of the TCUs in the plant network can access the USB
memory medium.
- USB global is not possible under Windows!
NW Windows/Linux Network drive
Local drive Local drive
Hard disk or user memory on the CompactFlash card.
Type
FTP Access to an external FTP server.
Front USB interface that is located at the front of the operator
panel.
X203/X204
USB interface X203/X204 that is located at the rear of the
operator panel.
Connection
X204 For SIMATIC Thin Client the USB interface is X204.
Device Names of the TCU to which the USB storage medium is
connected, e.g. tcu1. The NCU must already know the
TCU name.
Partition Partition number on the USB memory medium, e.g. 1.
If a USB hub is used, specify the USB port of the hub.
Port Interface for the FTP connection. The default port is 21.
Disconnect After a disconnect timeout, the FTP connection is
disconnected. The timeout can be between 1 and 150 s.
10 s is the default setting.
Path
• Start direct directory of the data carrier that is
connected via the local drive.
• Network path to a directory that has been released in
the network. This path must always start with "//", e.g.
//Server01/share3.
