Programming technology functions (cycles)
8.3 Contour turning
Turning
368 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
Parameter Description Unit
Allowance Allowance for pre-finishing - (only for ∇∇∇)
• Yes
U1 contour allowance
• No
mm
U1 Compensation allowance in X and Z direction (inc) – (only for allowance)
• Positive value: Compensation allowance is kept
• Negative value: Compensation allowance is removed in addition to finishing
allowance
mm
Set machining area
limits
Set machining area limits
• Yes
• No
XA
XB
ZA
ZB
with limited machining area only, yes:
1. Limit XA ∅
2. Limit XB ∅ (abs) or 2nd limit referred to XA (inc)
1. Limit ZA
2. Limit ZB (abs) or 2nd limit referred to ZA (inc)
mm
N Number of grooves
DP Distance between grooves (inc) mm
* Unit of feedrate as programmed before the cycle call
8.3.11 Plunge-cutting rest (CYCLE952)
Function
The "Grooving residual material" function is used when you want to machine the material
that remained after grooving along the contour.
During grooving ShopTurn, the cycle automatically detects any residual material and
generates an updated blank contour. For a G code program, the function must have been
previously selected. Material that remains as part of the finishing allowance is not residual
material. The "Grooving residual material" function allows you to remove unwanted material
with a suitable tool.
Software option
To machine residual material, you require the "Residual material detection
and machining" option.
