Tool management
11.5 Tool list
Turning
Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
601
11.5.8 Code carrier connection (only 840D sl)
11.5.8.1 Overview
You have the option of configuring a connection to MCIS TDI Ident Connection.
This means that the following functions are available in SINUMERIK Operate:
● Creating a new tool from code carrier
● Unloading tools on code carrier
Software option
In order to use the functions, you require the option "MC Information System TDI
Ident Connection".
References
Further details on tool management with code carrier and the configuration of the user
interface in SINUMERIK Operate can be found in the following reference:
● Function Manual MCIS TDI Ident Connection
● Commissioning Manual SINUMERIK Operate (IM9) / SINUMERIK 840D sl
For the code carrier connection, in addition there is a tool available in the list of favorites.
Figure 11-17 New tool from code carrier in the list of favorites
