Machining the workpiece
4.13 Mold making view
Turning
170 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
Press the "Details" and "Auto zoom" softkeys if you wish to
automatically adapt the segment to the size of the window.
The automatic scaling function "Fit to size" takes account of the largest
expansion of the workpiece in the individual axes.
Note
Selected section
The selected sections and size changes are kept as long as the program is selected.
4.13.5.2 Modifying the viewport
Use the magnifying glass if you would like to move, increase or reduce the size of the
section of the mold making view, e.g. to view details or display the complete workpiece.
Using the magnifying glass, you can define your own segment and then increase or
decrease its size.
Precondition
● The mold making view has been started.
● The "Graphic" softkey is active.
Procedure
1. Press the "Details" softkey.
2. Press the "Zoom" softkey.
A magnifying glass in the shape of a rectangular frame appears.
3. Press the "Magnify +" or <+> softkey to enlarge the frame.
- OR -
Press the "Magnify -" or <-> softkey to reduce the frame.
- OR -
