Programming technology functions (cycles)
8.7 Additional cycles and functions in ShopTurn
Turning
496 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
Parameters Description Unit
Retraction - (only for "chipbreaking" operation)
Retraction distance
• Manual
• Automatic
V2 Retraction distance (only for "manual" retraction)
Distance through which the tap is retracted for chipbreaking.
V2 = automatic: The tool is retracted by one revolution.
mm
8.7.3 Transformations
To make programming easier, you can transform the coordinate system. Use this possibility,
for example, to rotate the coordinate system.
Coordinate transformations only apply in the actual program.
You can define the following transformations:
● Offset
● Rotation
● Scaling
● Mirroring
● Rotation C axis
You can select between a new or an additive coordinate transformation.
In the case of a new coordinate transformation, all previously defined coordinate
transformations are deselected. An additive coordinate transformation acts in addition to the
currently selected coordinate transformations.
Note
Transformations with virtual axes
Please note that when selecting TRANSMIT or TRACYL offsets, scaling and mirroring, the
real Y axis is not transferred into the virtual Y axis.
Offsets, scalings and mirroring of the virtual Y axis are deleted for TRAFOOF.
