Overview of display
Display Meaning
Header columns
Work/Machine Display of axes in selected coordinate system.
Position Position of displayed axes.
Display of distance-to-go The distance-to-go for the current NC block is displayed while the
program is running.
Feed/override The feed acting on the axes, as well as the override, are displayed
in the full-screen version.
Repos offset The distances traversed in manual mode are displayed.
This information is only displayed when you are in the "Repos"
submode.
The collision avoidance is switched on for the JOG and
MDI or AUTOMATIC modes and at least one active
collision pair is present.
Collision monitoring
(only 840D sl)
The collision avoidance is switched off for the JOG and
MDI or AUTOMATIC modes or no active collision pair is
present.
Footer Display of active work offsets and transformations.
The T, F, S values are also displayed in the full-screen version.
See also
Zero offsets (Page 82)
1.4.4 T,F,S window
The most important data concerning the current tool, the feedrate (path feed or axis feed in
JOG) and the spindle is displayed in the T, F, S window.
In addition to the "T, F, S" window name, the following information is also displayed:
Display Meaning
BC (example) Name of the tool carrier
Turning (example) Name of the active kinematic transformation
Active tool carrier rotated in the plane
Active tool carrier swiveled in space
