Introduction
1.4 User interface
Turning
44 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
Tool data
Display Meaning
T
Tool name Name of the current tool
Location Location number of the current tool
D Cutting edge of the current tool
The tool is displayed with the associated tool type symbol corresponding to
the actual coordinate system in the selected cutting edge position.
If the tool is swiveled, then this is taken into account in the display of the
cutting edge position.
In DIN-ISO mode the H number is displayed instead of the cutting edge
number.
H H number (tool offset data record for DIN-ISO mode)
If there is a valid D number, this is also displayed.
Ø Diameter of the current tool
R Radius of the current tool
Z Z value of the current tool
X X value of the current tool
Feed data
Display Meaning
F
Feed disable
Actual feed value
If several axes traverse, is displayed for:
• "JOG" mode: Axis feed for the traversing axis
• "MDA" and "AUTO" mode: Programmed axis feed
Rapid traverse G0 is active
0.000 No feed is active
Override Display as a percentage
