Managing programs
12.15 Backing up data
Turning
672 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
9. Select the required location for archiving and press the "New directory"
softkey to create a suitable subdirectory.
The "New Directory" window opens.
10. Enter the required name and press the "OK" softkey.
The directory is created below the selected folder.
11. Press the "OK" softkey.
The "Generate Archive: Name" window opens.
12. Select the format (e.g. archive ARC (binary format)), enter the desired
name and press the "OK" softkey to archive the file/files.
A message informs you if archiving was successful.
13. Press the "OK" softkey to confirm the message and end the archiving
operation.
An archive file in .arc format is created in the selected directory.
12.15.3 Reading in an archive in the Program Manager
In the "Program Manager" operating area, you have the option of reading in archives from
the archive folder of the system data as well as from configured USB and network drives.
Software option
In order to read-in user archives in the "Program Manager" operating area,
you require the option "Additional HMI memory on CF Card of NCU" (not for
SINUMERIK Operate on PCU50 / PC).
Procedure
1. Select the "Program Manager" operating area.
2. Press the "Archive" and "Read in archive" softkeys.
The "Read in archive: Select archive" window opens.
