Ladder Viewer and Ladder add-on (828D only)
23.18 Displaying the network symbol information table
Turning
804 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
23.18 Displaying the network symbol information table
All of the symbolic identifiers used in the selected network are displayed in the "Network
symbol information table" window.
The following information is listed:
● Names
● Absolute addresses
● Comments
The symbol information table remains empty for networks that do not contain any global
symbols.
Procedure
1. The ladder diagram display (LAD) is opened.
2. Select the desired network and press the "Symbol info" softkey.
The "Network Symbol Information Table" window appears.
3. Use the cursor keys to move within the table.
