Multi-channel machining (only 840D sl)
9.2 Multi-channel support (only 840D sl)
Turning
Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
539
9.2.4 Multi-channel functionality for large operator panels
For the large OP15, OP019 operator panels as well as at the PC, there is more space in the
"Machine", "Program" and "Parameter" operating areas – as well as in all lists – to display
NC blocks, tools etc.
Further, you also have the option of simultaneously displaying more than 2 channels.
This makes it easier for you to identify the machine situation for machines with 3 and more
channels. Further, it makes it simpler for you to generate and run-in three or four-channel
programs.
Software options
If you require the option "programSYNC" for the views described here.
Supplementary conditions
● OP15, OP19 or PC with a display of at least 1280x1024 pixels
● For operating an OP019, at least one NCU720.2 or 730.2 with 1 GB of RAM or a PCU50
is required
3 / 4-channel view in the "Machine" operating area
If you have selected 3 channels via settings, then 3 or 4 channel columns are displayed next
to one another.
Channel view Display in the "Machine" operating area
3-channel view The following windows are displayed one above the other for each channel:
• Actual value window
• T,F,S window
• Block display window
4-channel view The following windows are displayed one above the other for each channel:
• Actual value window
• T,S,F window
• G functions (the "G functions" softkey is omitted)
• Block display window
