Working with a B axis (only 840D sl)
15.8 Measuring a tool with the B axis
Turning
Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
735
Procedure
Aligning the milling and turning tool with β angle:
Press the <SELECT> key and select
• 0° or
• 90° or
• Value entry box to freely enter the angle.
Aligning the turning tool with γ angle:
Press the <SELECT> key and select
• 0°
• 180°
• Value entry box to freely enter the angle.
See also
Selecting a tool and spindle (Page 101)
15.8 Measuring a tool with the B axis
When measuring manually, traverse the tool manually to a known reference point in order to
determine the tool dimensions in the X and Z directions. The control system then calculates
the tool offset data from the position of the tool carrier reference point and the reference
point.
To determine the tool dimensions, the orientation, i.e. the β angle, must be specified.
The γ angle input box is also provided for turning tools.
Reference point
The workpiece edge is used as the reference point when measuring length X and length Z.
The chuck of the main or counterspindle can also be used when measuring in the Z
direction.
Specify the position of the workpiece edge during the measurement.
β angle
In order to measure milling and turning tools, you can select the two main settings β = 0° and
β = 90° and a value input field.
γ angle
In order to measure turning tools, you can select the γ angle 0° and 180°.
