Programming technology functions (cycles)

8.7 Additional cycles and functions in ShopTurn

Turning

Operating Manual, 03/2013, 6FC5398-8CP40-3BA1

499

8.7.5 Rotation

You can rotate every axis through a specific angle. A positive angle corresponds to

counterclockwise rotation.

New rotation

Additive rotation

Parameters Description Unit

Rotation

• New

• New rotation

Z Rotation around Z Degrees

X Rotation around X Degrees

Y Rotation around Y Degrees
